Our range of international certified AIS transponders fit the requirement of each individual customer. Combined with various available electronic display systems, your safety and navigation ability is enhanced significantly. It increases the "visibility" of any vessel carrying one and eliminates the problem of restricted radar coverage.
AIS is used world wide today in search and rescue (SAR) operations, coastal surveillance, national security monitoring, environmental protection, icebreaker operations and asset tracking. AIS is also used to increase the efficiency of port and waterway operations. There are various AIS Satellite tracking systems available.
AIS is fitted on leisure craft, commercial, security and military vessels, icebreakers, SAR vessels, planes and helicopters, tugs and barges, to name a few.
Automatic Identification System (AIS) is an automatic tracking system that uses an AIS transponder on ships and is used by vessel traffic services (VTS). When satellites are used to detect AIS signatures, the term Satellite-AIS (S-AIS) is used. AIS transponder information supplements marine radar, which continues to be the primary method of collision avoidance for water transport.
Information provided by an AIS transponder, such as unique identification, position, course, and speed, can be displayed on a screen or an ECDIS. AIS is intended to assist a vessel’s watchstanding officers and allow maritime authorities to track and monitor vessel movements. AIS integrates a standardized VHF transceiver with a positioning system such as a GPS receiver, with other electronic navigation sensors, such as a gyrocompass or rate of turn indicator. Vessels fitted with AIS transceivers can be tracked by AIS base stations located along coast lines or, when out of range of terrestrial networks, through a growing number of satellites that are fitted with special AIS receivers which are capable of deconflicting a large number of signatures.
The International Maritime Organization’s International Convention for the Safety of Life at Sea requires AIS Class A to be fitted aboard international voyaging ships with 300 or more gross tonnage (GT), and all passenger ships regardless of size. For a variety of reasons, ships can turn off their AIS Class A transponders.
AIS Class B transceivers were pioneered to offer AIS benefits to smaller vessels. Class B devices offer lower power, fewer receivers and different display options to a Class A transceivers. Coupled with cost savings, Class B devices are ideal for mariners with small pleasure craft or fishing boats.
Class B transceivers offer small vessels all the AIS features of Class A devices, but without some of the requirements needed for larger vessels. Class B devices offer:
AIS Class B units are designed for smaller vessels with fewer power options, less space and fewer antennas than a large commercial vessel. The lower transmission power means their range is significantly less than a Class A device, but this is compensated by the anticipated stopping distance in an emergency situation of the vessel compared to a large commercial vessel.
Class B devices are a lot smaller than a Class A device, ensuring they can be installed quickly and integrated easily to many different displays. As smaller vessels rarely include a second antenna, most Class B devices need to use an antenna splitter to regulate use of the VHF antenna between the VHF radio and AIS device.
Small and lightweight, they deliver the very best AIS receive and transmit performance so you see more AIS information and targets at maximum range with the least power consumption.
With built-in intelligent connectivity, integrated next generation GPS and the unique FLEXI-FIX™ bracket system, safe and secure installation could not be easier.
B900 CSTDMA Variants
Small and lightweight, they deliver the very best AIS receive and transmit performance so you see more AIS information and targets at maximum range with the least power consumption.
With built-in intelligent connectivity, integrated next generation GPS and the unique FLEXI-FIX™ bracket system, safe and secure installation could not be easier.
B900 SOTDMA Variants
The B200 is a high transmit power (5W) priority AIS Class B transponder, ideal for serious ocean sailors.
The high powered AIS engine delivers complete reliability and the very best AIS performance in terms of range and capacity.
An internal battery is constantly maintained fully charged and ensures continuous operation for up 120 hours in the event of vessel power loss.
Silent mode, where transmissions are switched off, but receiving continues, is easily enabled through the integrated switch or via your mobile phone using our CONNECT-AIS app.
Completely water and weather proof (IPx6 & IPx7 certified) and ruggedized to withstand shock and vibration the B200 will operate reliably for years in even the most extreme marine environments.
The dual NMEA2000 & 0183, coupled with serial ports, USB, WiFi, and Bluetooth make connecting to all your tablets, PC’s, display and navigation devices plug & play.
Key Features
The B400 Class B/SO is a fully integrated high-powered priority transmit AIS Class B transceiver.
The B400 delivers enhanced range and performance in busy areas and open ocean.
It is a single integrated and small unit which is certified weather and water proof, with integrated colour display.
The B400 is easy to install, use, and integrate with all bridge systems.
The B400 offers full range of sophisticated AIS functionality such as alerts, target filters, vessel information lists, real time weather and more.
Key Features
The I100 Small Vessel Tracker is a fully integrated AIS Class B transceiver.
The em-trak AIS I100 Identifier is a fully integrated Class B vessel tracking AIS transponder.
TheVHF & GPS antennas and batteries are integrated within a security sealed IPx8 waterproof ruggedized shell.
The internal rechargeable battery gives over 5 days of continuous operation within charges. The I100 Identifier is supplied as a complete kit with vessel mounting bracket and mains rapid charging dock.
NOTE: The unit will not function until programmed with the vessel details and a UNIQUE MMSI number. Single units can be programmed prior to dispatch or multiple units can be programmed using the Identifier I100 Configuration Kit 417-0047.
Key Features
The A200 is a fully integrated AIS Class A transceiver which is both SOLAS and Inland Waterway certified.
The A200 is compliant with all national and international (IMO) commercial vessel AIS regulations.
The A200 Transponder is a single integrated and small unit which is water and weather proof (IPx6 & IPx7), with integrated colour display.
The A200 is easy to install, use, and integrate with all bridge systems.
The A200 offers full range of sophisticated AIS functionality such as alerts, target filters, vessel information lists, real time weather and more.
Key Features
The SART100 is an IMO-SOLAS certified AIS search and rescue transponder.
Engineered for complete reliability, SART100 can be stored for years.
When needed can be instantly activated to transmit an emergency transmission, which all AIS equipped vessels, coast guard and aircraft will receive and pin-point your exact location.
The SART100 is ruggedized - IPx6, IPx7 and IPx8 and comes as a complete kit ready to go and can be stored away for many years ready for instant activation in the event of an emergency.
Key Features
